LED Strip Controllers (65)

6 channel SPI LED strip repeater For use with SPI LED strip Input Voltage: 12v DC or 24v DC 3 years replacement warranty Install Sheet Download

RGB SPI Remote Controller Individual Colour Controls 9 Preset Colours 2 Saved Settings Must be used with HV9105-SPI-2CH IP rating: IP20 Input voltage: 3v (CR2032) 3 years replacement warranty Data Sheet Data Sheet Install Sheet Download

Dali DT8 LED strip controller For use with CT, RGBW + RGBCW LED strip Built-in DALI-2 interface, DALI DT8 device Multi-addresses enabled DT8 control gear Multi-devices integrated in one control gear Multi-functional, 7 in 1: Tc, RGBWAF, XY, 2*Tc, XY+Tc, RGB+Tc, XY+W (DT6) DALI address manually assignable through manual set buttons and showed on the display Can be set as different device types: single-address types or multi-addresses types Single-address device types: Tc, RGBWAF, XY Multi-addresses device types: 2*Tc, XY+Tc, RGB+Tc, XY+W (DT6) 5 Channels constant voltage output Control of five PWM outputs via DALI device type 8 Colour control as defined in the DALI specification device type 8 Supports DT8 device commands, compatible with universal DALI masters that support DT8 commands Configuration via DALI master USB interface Colour temperature and RGB Colour control through push dim mode even without DALI Input voltage: 12v DC or 24v DC Max Load: 12v DC 300w / 24v DC 600w 3 years replacement warranty (items ordered after 01/01/22) Data Sheet Data Sheet Install Sheet Installation Instructions Video Instructions Instructional Video

RGBC or RGBW LED Touch Panel For use with RGB, RGBC and RGBW Lights or LED Strip 3 Zones Dimming range: 5-100% Operation Frequency: 2.4GHZ Must be used with HV9105-1009-5C IP Rating: IP20 Input Voltage: 240 AC 3 Years replacement warranty (items ordered after 01/01/22) Data Sheet Download Install Sheet Download

Single Coloured LED Touch Panel For use with Single Colour LED Strip 3 scenes Presets 4 Zones Dimming range: 5-100% Operation Frequency: 2.4GHZ Must be used with HV9105-1009-5C IP Rating: IP20 Input Voltage: 240 AC 3 Years replacement warranty (items ordered after 01/01/22) Data Sheet Data Sheet Install Sheet Installation Instructions

Single Colour touch panel controller For use with LED strip Input voltage: 240v AC IP Rating: IP20 Output signal: 2.4ghz + DMX512 Transmitting range: 30m approx Dimming Range: (5%-100%) To be used with HV9103-F4-5A Can be used with DMX Controller - View Here IP Rating: IP20 3 years replacement warranty Specification Sheets Data Sheet Installation Instructions

LED strip recieving controller For use with RGBCW Lighting or LED strip To be used with HV9101-EX5S + HV9102-Q5 Can be used with DMX Systems IP Rating: IP20 Max Load: 12v DC 240w / 24v DC 480w Input voltage: 12v DC or 24v DC 3 years replacement warranty Data Sheet Data Sheet Install Sheet Installation Instructions

RGBCW LED Strip Touch Panel 4 Scenes Input voltage: 240v AC Must be used with HV9103-F5-DMX-4A IP Rating: IP20 3 years replacement warranty (items ordered after 01/01/22) Data Sheet Download Install Sheet Download

WIFI + RF LED Strip Receiver  Can be used with Remote Controllers, Touch Panels or TUYA APP  Works with Google Home & Amazon Alexa Can be used with all LED Strip Input Voltage: 12-24v DC Output Power: 5CH x 4A (240W-480W) Operation Frequency 2.4GHZ IP Rating: IP20 3 Years replacement warranty (items ordered after 01/01/22)  Data Sheet Data Sheet Install Sheet Installation Instructions Video Instructions Instructional Video Compatible Controllers  Single Colour Touch Panel Single Colour Remote HV9101-2830A HV9102-2819DIM RGBC OR RGBW TOUCH PANEL RGBC OR RGBW REMOTE HV9101-2820 HV9102-2819RGBW RGBCW TOUCH PANEL RGBCW REMOTE HV9102-2834-5C HV9102-2858Z4-5C CT TOUCH PANEL CT REMOTE HV9101-2830B HV9102-2819CCT

RGBCW LED Strip Touch Panel 4 scene presets Input voltage: 12V DC or 24v DC Output power: 12v DC: RGB = 108w | CT = 36w / 24v DC: RGB = 216w | CT 72w IP Rating: IP20 3 years replacement warranty (items ordered after 01/01/22) Data Sheet Download Installation Instructions Download

5 Channel LED strip repeater Enables additional loads to be controlled from 1 controller For use with all LED strip exc. SPI Input Voltage: 12v DC or 24v DC Max Load: 12v DC 360w / 24v DC 720w  3 years replacement warranty (Items ordered after 01-01-2022) Data Sheet Download Installation Instructions Download
